      • Welcome to HIVATECH

      • Advanced Application Concept of Die Casting Vacuum

      • First Class R & D and Technical Service Team

      About Us

      HIVATECH (Anshan) Co. Ltd was established in 2010. Located in Anshan, Liaodong Peninsula, its predecessor is Anshan HIVATECH Vacuum Equipment Manufacturing Co. Ltd. A professional manufacturer of die casting vacuum systems, HIVATECH has continuously invested in R&D and made significant breakthroughs in product and system development, winning many national patents. HIVATECH independently developed Hi-Vacuum unit with dual system and s-type vacuum valve, which greatly improved the vacuum efficiency of the system and attained CE certification in 2018.

      Mobile Vacuum Unit

      Split type vacuum machine and split type vacuum machine, convenient and flexible installation, various models, suitable for different sizes of die casting machines.

      Vacuum Station & Vacuum Unit

      Consists of work pump, spare pump and vacuum tank. The capacity of vacuum station will be customized to suit customers actual requirements. HIVATECH will provide a complete set of layout plan.

      Hi-Vacuum & Super-vacuum Valve

      HIVTECH’s patented product consisting of two independent vacuum systems.

      Why choose Hivatech?

      HIVATECH has developed the unique know-how by applying the most advanced vacuum technologies of diecasting and has been providing the most efficient package solution for high quality diecasting products at the most economical cost.

      Applying the most advanced vacuum technologies of diecasting, HIVATECH has been providing efficient packaged solutions for high quality diecasting products at the most economical cost. HIVATECHTM’s unique value also lies in customized service and has longstanding partnerships with several major players in die-casting industry.

      Patents and Certifications

      CE Certification

      Super Valve

      Pneumatic Valve

      Pre-vac Valve

      Dual System Hi-vac Unit

      Vacuum Damping Unit

      Tool Tight Test Unit and Leak Measure Method

      COMPATIBILITY WITH EVACUATION ELEMENTS

      Traditional positive vacuum valve
      Chill block
      Pneumatical vacuum valve
      Super vacuum valve
      Hydraulic vacuum valve

      OPERATION PANEL FUNCTIONS

      Real-time graph display
      Minimum 2000 sets of real-time vacuum history records
      Up to 50 sets of tool recipe
      Multilingual operating interface
      Automatic fault diagnosis
      Channel vacuum curve display
      Manual fine-tuning for sensors
      Phase protection
      Integral or independent selection of vacuum elements

      PROFINET COMMUNICATION

      Interface with DCM via profinet
      Vacuum data transferred to DCM via profinet.

      PROCESS CONTROLS

      Real-time feedback of cavity vacuum and manual testing
      Pollution monitoring of vacuum channel and manual testing
      Profile jam monitoring of chill block and manual testing
      Sleeve vacuum
      Sleeve vacuum damp function
      Individual blowing
      Mold leak test option

      0

      Years in Business

      0

      Projects Delivered

      0

      Satisfied Customers

      0

      Seconds on this site!
      What are you waiting for?

      Our Solutions

      ×

      HV1500

      Vacuum Unit HV1500

      Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be up to 6 channels as per requirement.

      project parameter project parameter
      DCM 4500ton Vac curve trigger
      Movable - Tool recipe 24
      Interface cable/network Channels 2xDN25
      Pump 200m3/h Chinese/English
      Power consumption 4KW Vac test
      Capacity 1500L Pollution test
      Ultimate vacuum 0.1mbar Profile test
      System vacuum <10mbar Channel blowing individual
      Compressed air 6bar Compatibility positive valve
      Air consumption 550L/min chill block
      Occupied area 1200×1800mm pneumanic valve
      Weight 550KG super vavle
      PLC S71200/1500 hydralic valve
      Touch panel TP700/900/1200

      HV1000

      Mobile Vacuum Unit HV1000

      Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be up to 6 channels as per requirement.

      project parameter project parameter
      DCM 3500ton Vac curve trigger
      Movable Tool recipe 24
      Interface cable/network Channels 2xDN25
      Pump 160m3/h Chinese/English
      Power consumption 4KW Vac test
      Capacity 1000L Pollution test
      Ultimate vacuum 0.1mbar Profile test
      System vacuum <10mbar Channel blowing individual
      Compressed air 6bar Compatibility positive valve
      Air consumption 550L/min chill block
      Occupied area 1000×1500mm pneumanic valve
      Weight 500KG super vavle
      PLC S71200/1500 hydralic valve
      Touch panel TP700/900/1200

      HV600

      Mobile Vacuum Unit HV 600

      Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be up to 6 channels as per requirement.

      project parameter project parameter
      DCM 1600ton Vac curve trigger
      Movable Tool recipe 24
      Interface cable/network Channels 2xDN25
      Pump 63m3/h Chinese/English
      Power consumption 2KW Vac test
      Capacity 600L Pollution test
      Ultimate vacuum 0.1mbar Profile test
      System vacuum <10mbar Channel blowing individual
      Compressed air 6bar Compatibility positive valve
      Air consumption 550L/min chill block
      Occupied area 950×1500mm pneumanic valve
      Weight 400KG super vavle
      PLC S71200/1500 hydralic valve
      Touch panel TP700/900

      HV800

      Mobile Vacuum Unit HV800

      Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be up to 6 channels as per requirement.

      project parameter project parameter
      DCM 2500ton Vac curve trigger
      Movable Tool recipe 24
      Interface cable/network Channels 2xDN25
      Pump 100m3/h Chinese/English
      Power consumption 3KW Vac test
      Capacity 800L Pollution test
      Ultimate vacuum 0.1mbar Profile test
      System vacuum <10mbar Channel blowing individual
      Compressed air 6bar Compatibility positive valve
      Air consumption 550L/min chill block
      Occupied area 950×1500mm pneumanic valve
      Weight 450KG super vavle
      PLC S71200/1500 hydralic valve
      Touch panel TP700/900

      Vacuum Station

      Central Vacuum Unit

      Consists of work pump, spare pump and vacuum tank. The vacuum system can be designed and customized to satisfy customers’ individual requirements for evacuation capacity, control as well as operation.
      Three stations as an integral group via common interface has been designed. It enables scalability and ensures safe operation of the system in case of future expansion plans.

      project HVS2000-200-3GS HV3000-300-3GS HV4000-300-4GS
      Power Supply 380VAC,50Hz 380VAC, 50Hz
      Vacuum Pump 3x200m3/h-4kW 3x300m3/h-7.5kW 4x300m3/h-7.5kW
      Vacuum Tank 2000 L 3000 L 4000 L
      Min. area 3000Wx2500L3200Hmm 3500W3000Lx3500Hmm 4000Wx3500Lx3800Hmm
      350~1650 ton DCM 15 Unit 25 Unit 35 Unit
      1650~4000 ton DCM 8 Unit 13 Unit 18 Unit

      Vacuum unit

      Central Vacuum Unit

      Central Vacuum Unit is the more economical choice when five or more vacuum units are applied. Option of either integral or split type,  including operational panel and main valve box. Standard setup includes 2 cbannels which can be customized to be up to 6 channels as per requirement.

      Vacuum unit  HV350CSH HV350CSM
      Power Supply 220 VAC, 50Hz 220 VAC, 50Hz
      PLC S7-1500 Siemens S7-1200 Siemens
      Touch panel TP900~TP1200 Siemens TP700 Siemens
      Compressed Air 6 bar 6 bar
      Air consumption 550 l/min 550 l/min
      Occupied area 300X600X600 mm 300X600X600 mm
      Weight 70 kg 70 kg
      Al weight Up to 45kg Up to 45kg
      DCM Up to 4500 ton Up to 4500 ton
      Interface cable/network cable/network
      STD Vacuum Channel 2xDN25 2xDN25

      Hi Vacuum System

      Hi Vacuum System HIVTECH’s patented product

      This is HIVTECH’s patented product consisting consists of 2 independent vacuum system. Specially designed for sleeve evacuation and cavity exhaust with hydraulic valves or pneumatic valves in the application of automobile structure parts.

      Vacuum signals are received from DCM decoder. The start and end of sleeve and cavity vacuum could be set independently. In manual mode, the mold leaking test could be done. The damp function has been applied for sleeve evacuation in order to prevent excessive exhausting in the very initial stage.


      Hi-vacuum system HVH1000/1000-160160SHR HVH800/800-100100SHR HVH500/500-6363SHR HVH300/300-4040SHR
      Power supply 380VAC, 50Hz 380VAC, 50Hz 380VAC, 50Hz 380VAC, 50Hz
      Power consuption 2x4kW 2x3kW 2x2kW 2x1.5kW
      PLC Siemens S7-1500 Siemens S7-1500 Siemens S7-1500 Siemens S7-1500
      Touch panel Siemens comfort TP900-TP1200 Siemens comfort TP900-TP1200 Siemens comfort TP900-TP1200 Siemens comfort TP900-TP1200
      Interface cable/network cable/network cable/network cable/network
      Pumps 2x160m3/h 2x100m3/h 2x63m3/h 2x40m3/h
      Tanks 2x1000 L 2x800 L 2x500 L 2x300L
      Channels 3 (up to 6) 3 (up to 6) 3 (up to 6) 3 (up to 6)
      Al weight 40kg以上 25~40kg 10~25kg 10kg以下
      DCM 4000~4500ton 2700~3500ton 1650~2500ton 1250ton

      Vacuum Vavle

      Super Vacuum Valve

      Dual vacuum channels in the valve working at low plunger velocity phase. The main channel is shut-off when auxiliary channel working at high plunger velocity phase in order to maintain the high vacuum in cavity to the last minute.

      With Hivatech Vacuum unit, the evacuation capability is 50% more than normal valve.
      - High anti-pollution and repeatability
      - Channel Vacuum measuring & feedback
      - Simple and easy mounting and maintenance
      - Applicable for Aluminum and Magnesium Alloy Casting
      - Patented Product

      Super vavle Al weight DCM Vac unit
      HVSC 0.5 – 2.5 300 – 1000 all units
      HVMC 2.5 – 6.5 1250 – 2500 all units
      HVLC 6.5 – 12.5 1650 – 2800 HV600S abv,or HV350CS
      HVXC 12.5– 21 2800 – 4000 HV800S abv,or HV350CS

      HV300

      Mobile Vacuum Unit HV 300

            Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be customized tobe up to 6 channels as per requirement.
      project parameter project parameter
      DCM 1000ton以下 Vac curve trigger
      Movable Tool recipe

      24

      Interface cable/network Channels 2xDN25
      Pump 40m3/h Chinese/English
      Power consumption 1.5KW Vac test
      Capacity 300L Pollution test
      Ultimate vacuum 0.1mbar Profile test
      System vacuum <10mbar Channel blowing individual
      Compressed air 6bar Compatibility positive valve
      Air consumption 550L/min chill block
      Occupied area 800×1400mm pneumanic valve
      Weight 350KG super vavle
      PLC S7-1200 hydralic valve
      Touch panel TP700/900

      Hydraulic Station

      Integrated auxiliary hydraulic station with hi-vacuum system

      Integrated auxiliary hydraulic station with hi-vacuum system, to provide hydraulic control for hydraulic vacuum valves. The integrated system is the solution for the customers who are unable to make use of existing hydraulic system of the DCM. All controls are done by the integrated panel, making the operation more user-friendly.

      Hydraulic System HVY100HDS
      Power supply 380VAC, 50Hz
      Power consumption 11kW
      Hydraulic pump 40l/min
      Oil Tank 400l
      Pressure sensor 1
      Control valve 1-3
      Accumulator 1
      Temperature sensor 1

      Hv220

      Mobile Vacuum Unit HV 220

      Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be customized tobe up to 6 channels as per requirement.

      project parameter project parameter
      DCM 500ton Touch panel 7”smartline
      Movable Vac curve real time
      Interface cable Tool recipe 24
      Pump 40m3/h Channels 2xDN25
      Power consumption 1.5KW Chinese/English
      Capacity 220L Vac test
      Ultimate vacuum 0.1mbar Pollution test
      System vacuum <10mbar Profile test
      Compressed air 6bar Channel blowing inner
      Air consumption 550L/min Compatibility positive valve
      Occupied area 600×1300mm chill block
      Weight 320KG pneumanic valve
      PLC smart200 super vavle

      News Information

      Vacuum Die Casting

      Vacuum Die Casting

      When excessive air is trapped inside the casting it will cause defects such as internal porosity or blisters on the surface. If normal venting is not sufficient, you can extract it out using vacuum.
